Mighty Mixer
Mighty Mixer
Mighty Mixer

Mighty Mixer

-

The Mighty Mixer is extremely versatile and durable. It will mix your Soap, Lotions, Dry Materials, Oil blends, Body Washes and much more.

  • Variable Speed Control – 0 to 2500rmp with the turn of a knob.
  • Telescoping Height adjustable stand can go from 42″ (107cm) to 78″ (198cm).
  • The entire motor assembly will pivot up or down to mix in containers of different heights.
  • Note: All Mighty Mixers require a lead time of 5-7 weeks.

From: $1,390.00

Build Your Mighty Mixer Bundle

Mighty Mixer

Motor Voltage Upgrade - 220V
$50.00

This mixer comes standard with a 120v motor. An upgrade may be necessary for International customers.

Mighty Mixer

Mighty Mixer Optional Tripod Base
$285.00

Complete with installation bolts.

Mighty Mixer

Hands-Free Pot Whipper
$165.00 – $215.00

Best for Soaps and General Use.

Mighty Mixer

Double High Shear Mixing Wand
$297.00 – $397.00

Best for Lip Balms, Body Butters, Lotions, Massage Oils, etc.

Shaft Coupling for Mighty Mixer

Shaft Coupling for Mighty Mixer
$80.00

Required for Pot Whipper or High Shear Blade shafts 36" and up.

Too many choices? Call us and we'll help you build the perfect system.
Description
  • Works very well with our Pot Tippers and Oil Heaters.
  • The easy to adjust Variable Speed Control will give you as much or as little speed as you need for mixing Soap, Lotions, Dry Materials, Oil blends, Body Washes, etc.
  • Designed to mix batches from 20lbs (9kg) up to 500 lbs (227kg)
  • Approximate trace times:
    • 30 lbs (14kg) to 110 lbs (50kg) is about 5 to 10 minutes at a little over half speed (1500 rpm).
    • 250 lbs (114kg) to 500 lbs (227kg) is around 15 to 20 minutes at about 1800 rpm.
  • Complete with a Heavy duty ½ hp Constant Torque Motor
  • Very easy to raise and lower by simply removing a pin and adjusting to your desired height
    • Height is adjustable in, 1”  (25mm) increments for exact positioning).
  • The entire motor assembly will also pivot up or down, from 0 degrees (vertical) to 90 degrees (horizontal).
    • Will also lock at 90 degrees horizontal for cleaning, or for readiness to insert into the Pot Tipper or Tank.
  • The mixing angle of the Mighty Mixer can be set anywhere from 0 to 60 degrees by adjustment of the Pivot Pin.
  • Comes standard with a Floor Mount Plate, for mounting permanently to a floor with 5/16” (8mm) anchors or bolts (not included).
    • The Floor Mount Plate can also be easily attached to the optional rolling Tripod Base with three bolts (included with Tripod Base).
Specifications
  • Heavy Duty Telescoping Tubular Box Frame
  • Overall Height: 78” (198cm)
  • Weight: Approx. 80 pounds
  • 12 gauge steel frame
  • The Floor Stand Mount and Motor Mount is 3/16” (5mm) steel plate
  • Industrial, Variable Speed Drive Control
  • NEMA 4/12 – Wash-Down Enclosure and Controls
  • Heat Sink Enclosure to guard electronic components, from overheating
  • 120 / 240 volt AC, 1/2 HP
  • Permanent Magnet, 90 volt, DC Motor.
  • Amp. draw is about 6.5 amps and 780 watts
  • NEMA Frame, TEFC, SCR rated (speed control rated)
  • Motor has permanently sealed lubricated, ball bearings.
  • High starting torque for heavy load conditions.
  • Wired for clockwise direction, can be reversed for counter clockwise direction.
  • Motor shaft is 5/8” (16mm)
